Monday Kids DC-DC Step Up Power Supply 35V Module Automatic Boost Module 3.0-35V to 3.5-35V 100W High Power Step Up Board Real-time Display
Payment Security
We are PayPal Verified
PayPal is a secure and trusted payment processing service that allows you to shop online. PayPal can be used at mondaykids.com to purchase items by Credit Card (Visa, MasterCard, Discover, and American Express), Debit Card , or E-check (i.e. using your regular Bank Account).
- Brand Name: Monday Kids
- Condition: New
- Type: Logic ICs
- Operating Temperature: none
- Model Number: boost module
- Dissipation Power: none
- Supply Voltage: Input voltage DC3 ~ 35V
- is_customized: Yes
- Input current: 9A(Max.)
- Output voltage: DC3.5-35V(It is a boost module,So output voltage is higher than input
- Output current: 6A (Max.)
- Output power: 75W
- Conversion efficiency: 96.7% (Max.)
- Output ripple: 24mV(TYP)
- Measuring range of onboard voltmeter: 4~40V
- Error: +/ -0.1V.
- Short circuit protection: Yes (limit current 14A).
- feature: modul display voltage
1.Description:
Automatic boost module provide a stable power supply.Applicable to unstable voltage source or voltage conversion.
2. Features:
1>. Small size.
2>. Simple wiring.
3>. Targeted.
4>. Custom installation.
5>. High power 100W.
6>. Switch display output and input voltage.
7>. Adjustable output voltage.
8>. Real-time display voltage.
9>. Comes with excellent heat sink
10>. Fixed mounting hole.
11>. High quality terminal block
3. Parameters :
No. | Parameter | Value |
1 | Input voltage | DC3 ~ 35V(Display will be abnormal if input less than 4V) |
2 | Input current | 9A(Max.) |
3 | Output voltage | DC3.5-35V(It is a boost module,So output voltage is higher than input voltage) |
4 | Output current | 6A (Max.) |
5 | Output power | 75W |
6 | Conversion efficiency | 96.7% (Max.) |
7 | Output ripple | 24mV(TYP) |
8 | Measuring range of onboard voltmeter | 4~40V, |
9 | Error | +/ -0.1V. |
10 | Short circuit protection | Yes (limit current 14A). |
11 | Input reverse protection | No (One diode can be connected in series by yourself if need protection) |
12 | Size | 67*43*12MM |
4. Use manual:
- . Connect load at OUT+ and OUT- at first.Please note the positive and negative.
- . Connect power supply at IN+ and IN-.Please note the positive and negative.
- . Press the button to switch the display input or output voltage value.
5. Warm tip:
When the high power load is connected, because the shock current of the start-up is very limited, it is recommended to start up and then connect the load.
6. Application:
1>. Ordinary power supply
2>. Battery charger
3>. LED drive power
4>. Instrument voltage display
5>. Test meter
6>. Circuit test
7. Frequency asked questions:
1>. Can it output 35V at 6A?
Q : No,it can not.The output max is 100W.Only 75W for stable operation.
2>. Can it meet : input 12V and output 5V?
Q : No,it can not.It is step up module. The output must higher input
8. Illustration:
- Unit Type: piece
- Package Weight: 0.05kg (0.11lb.)
- Package Size: 1cm x 1cm x 1cm (0.39in x 0.39in x 0.39in)
