Monday Kids Low-Pass Filter Plate Subwoofer Preamp Board 2.1 3-Channel DC 10-24V 22Hz-300Hz

$3.99
In stock

Hurry up! Save . Sale ends in:

Days

Hrs

Mins

Sec

  • Brand Name: Monday Kids
  • Condition: New
  • Type: Logic ICs
  • Supply Voltage: DC10-24V DC Single Power Supply
  • Operating Temperature: -20~60 Celsius
  • is_customized: Yes
  • Model Number: Subwoofer Preamp Board
  • Application: Electronic Circuit
  • Type: Home Amplifier
  • Channels: 3 (2.1)
  • Frequency Range: 22Hz-300Hz
  • Audio Input: Mono or Two-Channel
  • Audio Output: Mono
  • PCB Specifications: 78x32mm 1.6mm Thickness



Parameters:

Power supply voltage: DC10-24V DC single power supply
Frequency range: 22Hz-300Hz
Audio input: mono or two-channel
Audio output: Mono
PCB specifications: 78x32mm, Thickness: 1.6mm
PCB Materials: FR-4 ultra-hard glass plate
Finished board Weight: 30g
Plate mounting holes center to center spacing: 70x24mm, hole diameter: 3.2mm
Potentiometers axial center spacing: 32.5mm

  • Unit Type: piece
  • Package Weight: 0.04kg (0.09lb.)
  • Package Size: 1cm x 1cm x 1cm (0.39in x 0.39in x 0.39in)
