Monday Kids BMP180 Temperature Pressure Sensor Unleaded Module for GPS navigation Weather forecast GY-68 GY005

BMP180 Temperature Pressure Sensor Unleaded Module for GPS navigation Weather forecast GY-68

The BMP180 is a high precision, small volume, low energy consumption pressure sensor, and can be used in a mobile device.Its excellent performance, the absolute lowest precision can reach 0.03hPa, and the power consumption is very low, only 3 μBMP180 uses the 8-pin ceramic powerful leadless chip carrier (LCC) ultrathin package through I2C bus, can be directly connected with various microprocessor

Main features:

• Pressure range: 300~1100hPa (elevation 9000 meters ~-500 meters)

• The power supply voltage: 1.8V~3.6V (VDDA), 1.62V~3.6V (VDDD)

• LCC8 package: lead-free ceramics carrier package (LCC)

• Size: 3.6mmx3.8x0.93mm

• Low power consumption: 5 μ A, in the standard mode

• High precision: low power mode, the resolution is 0.06hPa (0.5 meters)

• High linear mode, the resolution is 0.03hPa (0.25 meters)

• With the temperature output

• The I2C interface

• Temperature compensation

• Lead-free, meets RoHS specifications

• MSL 1 reaction time: 7.5ms

• The standby current: 0.1 μ

• No external clock circuit

Typical applications:

1. GPS precise navigation (dead reckoning, upper and lower bridge detection etc.)

2. Indoor and outdoor navigation

3. Leisure, sports and health monitoring

4. The weather forecast

5. The vertical speed indicator (rising / sinking speed)

6. Fan power control

1 * BMP180 module
