Monday Kids 220V 4 Channel Wifi Relay Switch Module Phone APP Wireless Remote Control Jog Self-Lock Interlock w/Shell for Android IOS Phones
Payment Security
We are PayPal Verified
PayPal is a secure and trusted payment processing service that allows you to shop online. PayPal can be used at mondaykids.com to purchase items by Credit Card (Visa, MasterCard, Discover, and American Express), Debit Card , or E-check (i.e. using your regular Bank Account).
- Brand Name: Monday Kids
- Condition: New
- Type: Logic ICs
- Model Number: Wifi Relay Switch
- Operating Temperature: 0~60 celsius
- Dissipation Power: none
- is_customized: Yes
- Supply Voltage: 220V
- Application: Wifi Relay Switch
- Output Max Control Current: 10A
- Terminal Platform: Android/IOS
- Control Way: wifi 4-channel cell phone APP remote control + key manual control
After pressing the button for 5-6 seconds, the LED blinks quickly and the device is added to the operating device
Product Introduction:
1.Control Way:wifi 4-channel cell phone APP remote control + key manual control
2.Transmission Way:WIFI communication (support cell phone 2G,3G,4G network signal control at the same time)
3.Controllable Circuit:AC 86-265V power supply,4-channel passive output control;output is used as mechanical switch
4.Operating Voltage:AC 86-265V power supply;L connects with live line,N connects with zero line (NO,COM,NC) control output interface;when it is used as mechanical switch,NC is usually null,NO and COM form switch
5.Output Max Control Current:10A
6.Terminal Platform:Android/IOS
7.Operating Temperature:0~60 celsius
Features:
1.Inching/self-lock/interlock can be switched randomly;after finish setting,the mode won't change even if the module power off and restart
2.Inching:press the long key and then loosen,the relay will be on,and it will be off after 1s
3.Self-lock:press the long key and then loosen,the relay will be on;press again and it will be off
4.Interlock:when any one channel operates,other 3 channels will be closed
5.Press the MODE key on the module,the indicator lamp will flash for once and loosen it sets inching;if flashes for twice and loosen it sets interlock;if flash for three times and loosen it sets self-lock
6.Wifi cellphone APP remote intelligent control;after matching cellphone and the module,it can achieve long-distance control;it can function as manual key switch at the same time
Please download the picture of the app "eWeLink "
Matching Process:
1.Search "eWelink" and download the APP software
2.Install the APP
3.Use your phone number to register APP account number
4.After registration and log in the software
5.Long press random key S1-S4 for 5s on the controller,the indicator lamp will transform slow flash into uniform flash;then loosen the key,and select "+" to add device;click next step all the time until matching successfully
6.After auto adding,name the device by yourself and click finish
- Unit Type: piece
- Package Weight: 0.2kg (0.44lb.)
- Package Size: 15cm x 12cm x 10cm (5.91in x 4.72in x 3.94in)
