Monday Kids 10pcs Mini360 Mini-360 DC-DC HM Buck Converter Step Down Power Supply Module 4.75-23V to 1-17V 340KHz Ultra-small For Arduino
$3.71
Availability:
In stock
SKU
EK486
Payment Security
We are PayPal Verified
PayPal is a secure and trusted payment processing service that allows you to shop online. PayPal can be used at mondaykids.com to purchase items by Credit Card (Visa, MasterCard, Discover, and American Express), Debit Card , or E-check (i.e. using your regular Bank Account).
- Brand Name: Monday Kids
- Supply Voltage: 4.75-23V
- Operating Temperature: -40 celsius to +85 celsius
- Condition: New
- Model Number: DC-DC Buck Converter
- is_customized: Yes
- Type: Voltage Regulator
- Application: Electronic Circuit
- Input Voltage Range: 4.75-23V
- Output Voltage Range: 1-17V
- Switching Frequency: 340KHz
- Output Ripple: 30mV (no-load)
- Size: 17 * 11 * 3.8 mm
Description Model Name: Mini-360 (ultra small size DC-DC synchronous rectifier buck module
Module Properties: non-isolated buck
Rectification: synchronous rectification
Input voltage: 4.75V-23V
Output voltage: 1.0V-17V
Output Current: lowering the value of 3A, long 1.8A
Conversion efficiency: 96% (maximum)
Switching Frequency: 340KHz
Output ripple: 30mV (no-load)
Load regulation: ±0.5%
Voltage regulation: ±2.5%
Working temperature: -40 Centigrade to +85 Centigrade
External dimensions: 17 * 11 * 3.8 (L * W * H) (mm)
Features: Use integrally molded power inductor and synchronous rectifier control chip, smaller and more efficient.
- Unit Type: lot (10 pieces/lot)
- Package Weight: 0.025kg (0.06lb.)
- Package Size: 15cm x 12cm x 10cm (5.91in x 4.72in x 3.94in)
