Monday Kids Red DIY Heart Shape Breathing Lamp Kit DC4V-6V DIY Electronic Production DIY Kits Heart Shaped Lamp Suite Electronic DIY Kit
$1.45
Availability:
In stock
SKU
EK461
Payment Security
We are PayPal Verified
PayPal is a secure and trusted payment processing service that allows you to shop online. PayPal can be used at mondaykids.com to purchase items by Credit Card (Visa, MasterCard, Discover, and American Express), Debit Card , or E-check (i.e. using your regular Bank Account).
- Brand Name: Monday Kids
- Model Number: DIY Heart Shape breathing lamp kit
- Application: Computer
- Operating Temperature: none
- Condition: New
- Type: Logic ICs
- is_customized: Yes
- Dissipation Power: DIY Kits
- Supply Voltage: DC 4-6V
- Circuit board size: 50.7*50.7mm
- Packing weight: 13g/kit
- Light color: Red
- Name: electronic diy kit
1. Introduction
Light brightness automatically changes.
This is a DIY Heart Shape breathing lamp kit parts . You need solder it by yourself.
2.Parameter
NO. | Parameters | Value |
1 | Name | Heart shape led |
2 | Operating voltage | DC 4-6V |
3 | Difficulty of welding machine | Easy |
4 | Circuit board size | 50.7*50.7mm |
5 | Packing weight | 13g/kit |
3. Warm tips
This is the delivery suite of parts, you need welding installation. SCM has written code, successfully tested.
4.Schematic
5.Component listing
NO. | Component Name | PCB Marker | Parameter | QTY |
1 | Metal Film Resistor | R5 | 22R | 1 |
2 | Metal Film Resistor | R6 | 10K | 1 |
3 | Metal Film Resistor | R1,R2,R4 | 47K | 3 |
4 | Metal Film Resistor | R3 | 100K | 1 |
5 | Electrolytic Capacitor | C1 | 47UF | 1 |
6 | Potentiometer | VR1 | 50K | 1 |
7 | LM358 | U1 | DIP-8 | 1 |
8 | Power Switch | S1 | 6P | 1 |
9 | S8050 | Q1 | TO-92 | 1 |
10 | LED | LED1-LED22 | 5mm | 22 |
11 | PCB | 1 |
NOTE :Users can complete the installation by PCB silk screen and component listing.
