Monday Kids 12V 24V 36V LCD Digital Battery Capacity Monitor Panel Gauge Lithium Battery Status Indicator for Universal Auto Car Vehicle

Details

Brand Name: Monday Kids
Material: Mixture
Usage: Consumption Sensor
Theory: Current Sensor
Model Number: Batteries Indicator
is_customized: Yes
Type: Optical-Electronics Sensor
Output: Digital Sensor
Voltmeter Accuracy: 1%
Operating Humidity: 10 ~ 80%
Name: charge indicator

NOTE : we have documents of most of products in our store

If you need it , contact us :)

Features:

1.Superthin Type Electricity Display:5pcs LED indicator lamps

2.Wide Application Fields:lithium battery pack

3.Size:60*15*2.5mm

Using Method;

1.Connect display board positive and negative connection terminals with tested battery positive and negative ports,and press the red button lightly;then LED lamp will be on and display real-time battery electricity quantity

2.Loosen your finger,LED lamp will be off after 3-5s delay;when it is in quiescent state,it won't comsume any power

3.With anti-transposition function

Lithium Battery Pack Display Electricity Quantity Parameter:

1.When battery voltage is over N*3.2V,it will illuminate 1 block electricity quantity (note:N represents battery quantity)

2.When battery voltage is over N*3.4V,it will illuminate 2 blocks electricity quantity

3.When battery voltage is over N*3.6V,it will illuminate 3 blocks electricity quantity

4.When battery voltage is over N*3.8V,it will illuminate 4 blocks electricity quantity

----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Product Introduction:

1.Model:LY6W

2.Type:external installation

3.Screen Display:LCD

4.Application Battery:lead acid battery

Application Battery Specification:

1.Lead Acid Battery:24V

2.Operating Voltage:8-63V

----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Description:

1. Working current:5-15mA(The lower the battery voltage and current smaller)

2. Eight electricity Resolution:10% 25% 40% 50% 60% 75% 90% 100%

3. Voltmeter accuracy:1%

4. Working temperature: -10 ~ +65℃

5. Operating Humidity: 10 ~ 80%

6. Dimensions: 48*29*21 mm

Indicator:

Battery voltage is greater than 11.1V, 1 led indicator is lit.

Battery voltage is greater than 11.3V, 2 led indicator is lit.

Battery voltage is greater than 11.6V, 3 led indicator is lit.

Battery voltage is greater than 11.9V, 4 led indicator is lit.

Battery voltage is greater than 12.2V, 5 led indicator is lit.

Battery voltage is greater than 12.5V, 6 led indicator is lit.

Battery voltage is greater than 12.9V, 7 led indicator is lit.

Battery voltage is greater than 13.3V, 8 led indicator is lit.

NOTE:It will only display voltage if not measure lead-acid battery!!

----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Features:

1.Battery type electricity quantity display

2.Wide application fields:lithium battery

3.Using Method:connect display board positive and negative port with tested battery positive and negative port,digital tube will display real-time battery electricity quantity

4.Display Color:blue

Display Electricity Quantity Parameter:

1.When battery voltage is over N*3.3V,it will illuminate 1 block electricity quantity (note:N represents battery quantity)

2.When battery voltage is over N*3.5V,it will illuminate 2 blocks electricity quantity

3.When battery voltage is over N*3.7V,it will illuminate 3 blocks electricity quantity

4.When battery voltage is over N*3.9V,it will illuminate 4 blocks electricity quantity

5.When battery voltage is less than N*3.3V,4 blocks display will be off;it represents battery is less than 3.3V,and you can charge the battery
